Aluminum expanded metal mesh
Expanded metal mesh is also called pulledd plate wire mesh.
Process:A rigid piece of metal that has been slit and drawn into an open mesh pattern in a single operation. It is stronger, lighter in weight and more rigid than the original base metal.
Material:solid sheets or plates of carbon, galvanized and stainless steel, as well as aluminum and a variety of alloys of copper, nickel, silver, titanium, and other metals.
Mesh pattern:diamond, hexagonal, square,some special shapes
Specification:Aluminum expanded metal mesh
SWD(mm) | LWD(mm) | Mesh thickness(mm) | Strand(mm) | Weight(kg/m2) |
2.3 | 4 | 0.4 | 0.3 | 0.28 |
2.5 | 5 | 0.5 | 0.5 | 0.54 |
3 | 6 | 0.6 | 0.7 | 0.75 |
3.5 | 4 | 0.5 | 0.5 | 0.38 |
4 | 8 | 0.5 | 0.6 | 0.4 |
4.5 | 5 | 0.5 | 0.5 | 0.30 |
5 | 10 | 0.6 | 0.6 | 0.38 |
7 | 12 | 0.8 | 0.7 | 0.43 |
7 | 8 | 0.6 | 0.6 | 0.28 |
8 | 16 | 0.8 | 1.2 | 0.64 |
10 | 20 | 1.2 | 1.5 | 0.97 |
12 | 25 | 1.2 | 1.2 | 0.64 |
20 | 30 | 1.0 | 2.0 | 0.54 |
25 | 50 | 2.0 | 2.5 | 1.08 |
30 | 60 | 3.0 | 3.0 | 1.60 |
40 | 80 | 4.0 | 6.0 | 3.20 |
50 | 100 | 5.0 | 6.0 | 3.25 |
Your special specifications are available. And we can offer different surface finishing,for example, annealing,anodizing etc
